Interconnects and Custom PCB Test Modules Designing
Interconnects play a crucial role in any HILEVEL test setup, facilitate communication between the DUT and the testing equipment. These connections generally use compatible DUT Boards to create direct board-to-board connections within test fixtures. To ensure compatibility across different interfaces, adapter boards are implemented, while standard ribbon cables with connectors allow for extended connections between fixtures and testing devices. Our experience allows us to design interfaces compatible with third-party systems. Take a look at our offer to design interconnects and custom PCB test modules.
Interconnects play a crucial role in any ATE setup, facilitate communication between the DUT and the testing equipment. These connections generally use compatible DUT Boards to make direct board-to-board connections within test fixtures. To ensure compatibility across different interfaces, adapter boards are implemented, while standard ribbon cables with connectors allow for extended connections between fixtures and testing devices. Our experience allows us to design interfaces compatible with third-party systems. Take a look at our offer to design interconnects and custom PCB test modules.
What do we offer?
Remote Docking
These connections allow the DUT and test socket to be up to away from the tester. Solution available for all HILEVEL systems. We also design remote docking interfaces for third-party system.
DUT Boards & Adapters
DUT Borads and Adapters are custom-designed interfaces to connect DUT to ATE. We offer DUT Boards compatible with HILEVEL systems as well as possibility to design an interface for third-party systems.
Standard DUT Boards
HILEVEL offers DUT boards for your test fixturing needs. Each board is made to exacting standards with 6 to 12 layers, providing a controlled 50Ω environment all the way to the DUT pin.
Footprint Adapters
Footprint adapters are used for prototyping and pin pitch conversions. It allows you to solder a test chip on the top layer and route signals on the bottom layer. Make your prototyping a fantastic experience and let us design a footprint adapter for you.
Custom Load Boards
We design Custom PCB Test Modules that reduce the time needed to start testing a new electronic device. Installed multi-pin connector allows for quick replacement of DUTs, and the signals routed from the DUTs allow you to measure and switch them in a quick way.
